Outside Diameter：10L/140mm
| Type | WGA140-10-20 | Test Pressure | 300Bar |
| Outside Diameter | 140mm | Working Pressure | 200Bar |
| Capacity | 10L | Design Wall Thickness | 3.22mm |
| Height | 820mm | Material | 34CrMo4 |
| Weight | 13.6kg | Design Standards | ISO9809-1 Standard |
Outside Diameter：10L/159mm
| Type | WGA159-10-20 | Test Pressure | 300Bar |
| Outside Diameter | 159mm | Working Pressure | 200Bar |
| Capacity | 10L | Design Wall Thickness | 3.6mm |
| Height | 655mm | Material | 34CrMo4 |
| Weight | 13.8kg | Design Standards | ISO9809-1 Standard |
Outside Diameter：10L/165mm
| Type | WGA165-10-20 | Test Pressure | 300Bar |
| Outside Diameter | 165mm | Working Pressure | 200Bar |
| Capacity | 10L | Design Wall Thickness | 4.3mm |
| Height | 640mm | Material | 34CrMo4 |
| Weight | 14kg | Design Standards | ISO9809-1 Standard |
